| Model | SRD1600 | SRD2100 | SRD2500 | SRD3000 |
|---|---|---|---|---|
| Main shaft speed(rpm) | 73-347 | 73-347 | 73-347 | 73-300 |
| Ram travel(mm) | 470 | 470 | 470 | 270 |
| Rotor diameter(mm) | Φ530 | Φ530 | Φ530 | Φ650 |
| Number of rotor blades(pcs) | 54 | 69 | 72 | 52 |
| Number of fixed blades(pcs) | 17+2 | 20+2 | 23+2 | 25+2 |
| Discharge height(mm) | 792 | 792 | 792 | 1155 |
| Screen holes diameter(mm) | 40 | 40 | 40 | 80 |
| Motor power(kw) | 75X2 | 90X2 | 110X2 | 280 |
| Hydraulic power(kw) | 7.5 | 11 | 11 | 11 |
| Cutting chamber dimensions(mm) | 1593x1626 | 2055x1626 | 2517x1626 | 3006x1620 |
| Overall dimensions(LxWxH)(mm) | 2190x4100x2442 | 2190x4900x2442 | 2190x5400x2442 | 6620x2770x3955 |
| Weight(kg) | Approx 11000 | Approx 13500 | Approx 16000 | Approx 25000 |
