● Heavy duty close-gate design for more tighter bales
● Hydraulic locked gate ensures more convenient operation
● Unique double-cutting design of cutters improves the cutting efficiency and lengthens the lifespan of the cutters
● Particular anti-slide design of the machine makes nicer bales
● Unique trunnion-mounted frame and ball-end joint design for the main cylinder avoid the torque on the rod, which lengthens the lifespan of the seals
● The press heads are specially processed by planomiller, ensures the precise running of the ram
● Use high quality hydraulic valves from Taiwan, ensures the stable running of the machine
● The heavy duty machine body makes sure only flat ground is required by the installation
| Model | TY-1000WB11085 | TY-1000WB110110 |
| Pressure | 100tons | 100tons |
| Main Motor Power | 30kw | 30kw |
| Cooling System | air cooler / water cooler | air cooler / water cooler |
| Cycle Time (unload) | 36s | 42s |
| Oil Reservoir | 1460L | 1600L |
| Number of Belting | 4lines | 5lines |
| Wire Size | Ø3.0-3.2 | Ø3.0-3.2 |
| Feed Opening Size (L*W) | 1400*1050mm | 1800*1050mm |
| Chamber Size (L*W*H) | 3000*1050*830mm | 3700*1050*1050mm |
| Bale Size (L*W*H) | 1300*1100*850mm | 1600*1100*1100mm |
| Bale Density (OCC) | 500-600kgs/m3 | 500-600kgs/m3 |
| Throughput (approx./ depend on the raw material density, strapping skill and material feeding speed) | 1.5-3tons/h | 2-6tons/h |
| Machine Weight | 12tons | 18tons |
| Machine Overall Dimension | 7450*1600*2300mm | 8200*1600*3500mm |
| Feeding Device | Conveyor | Conveyor |
| Conveyor | ||
| Feeding Width | 1600mm | 1800mm |
| Speed | 12m/min | 12m/min |
| Power | 5.5KW | 7.5KW |
| Weight | 5tons | 7tons |
| Overall Dimension | 9000*2100*4200mm | 9500*2200*4200mm |
